SCM5B38-N

Strain Gauge Input Analog Modular Signal Conditioner

Dataforth

Strain Gauge Input Module
1500 V Transformer Isolation
Accuracy: ± 0.03%
Module
ANSI/IEEE C37.90.1 Transient Protection
Input Protected to 240 V AC Continuous

Specifications

Family

Dataforth 5B

Input Type

Strain Gauge

# of Inputs

1

Output Type

±5 V DC
±10 V DC

Bandwidth

4 Hz

Excitation

3.33 V DC
10 V DC

Isolation

Yes

Supply Power

5 V DC

Models

SCM5B38-31

Full Bridge, ± 10 mV Input, ± 5 V DC Output

SCM5B38-31D

Full Bridge, ± 10 mV Input, ± 10 V DC Output

SCM5B38-32

Full Bridge, ± 30 mV Input, ± 5 V DC Output

SCM5B38-32D

Full Bridge, ± 30 mV Input, ± 10 V DC Output

SCM5B38-33

Half Bridge, ± 10 mV Input, ± 5 V DC Output

SCM5B38-33D

Half Bridge, ± 10 mV Input, ± 10 V DC Output

SCM5B38-34

Half Bridge, ± 30 mV Input, ± 5 V DC Output

SCM5B38-34D

Half Bridge, ± 30 mV Input, ± 10 V DC Output

SCM5B38-35

Full Bridge, ± 20 mV Input, ± 5 V DC Output

SCM5B38-35D

Full Bridge, ± 20 mV Input, ± 10 V DC Output

SCM5B38-36

Full Bridge, ± 33.3 mV Input, ± 5 V DC Output

SCM5B38-36D

Full Bridge, ± 33.3 mV Input, ± 10 V DC Output

SCM5B38-37

Full Bridge, ± 100 mV Input, ± 5 V DC Output

SCM5B38-37D

Full Bridge, ± 100 mV Input, ± 10 V DC Output
