Vert-X 1300

Hall Effect Rotary Displacement Sensor

Novotechnik

  • Compact Contactless Rotary Sensor
  • Ratiometric, PWM, SPI, SSI or Incremental Output
  • Connection: Ratio.: 3 Wires
  • Connection: PWM: 3 Wires
  • Connection: SPI: 6-pole Ribbon Cable
  • Long Lifetime

Specifications

Type
Analog
Non-Contact
Full Scale
360°
Max Speed
6000 RPM
Output
Ratiometric
PWM
SPI
Non-Linearity
±0.30 % FS
Resolution
0.1°
Excitation
5 V DC
IP Rating
IP54
IP65
Min Temperature
-40 °C
Max Temperature
105 °C
125 °C

Models

Vert X-1300-251
PWM Output
Vert-X-1300-221
Ratiometric Output
Vert-X-1300-281
SPI Output

Downloads

Vert-X1300 Ratiometric Output
Datasheet
Vert-X 1300 PWM Output
Datasheet
Vert-X 1300 SPI Output
Datasheet
