SCM5B34

RTD Input Analog Modular Signal Conditioner

Dataforth

Linearized 2- or 3-Wire RTD Input Module
1500 V Transformer Isolation
Accuracy: ± 0.06°C to ± 0.36°C
Module
ANSI/IEEE C37.90.1 Transient Protection
Input Protected to 240 V AC Continuous

Specifications

Family

Dataforth 5B

Input Type

RTD

# of Inputs

1

Output Type

0 - 5 V DC
0 - 10 V DC

Bandwidth

4 Hz

Isolation

Yes

Supply Power

5 V DC

Models

SCM5B-34N-01

120 Ω Ni, 0-300°C Input, 0-5 V DC Output

SCM5B34-01

100 Ω Pt, ± 100°C Input, 0-5 V DC Output

SCM5B34-01D

100 Ω Pt, ± 100°C Input, 0-10 V DC Output

SCM5B34-02

100 Ω Pt, 0-100°C Input, 0-5 V DC Output

SCM5B34-02D

100 Ω Pt, 0-100°C Input, 0-10 V DC Output

SCM5B34-03

100 Ω Pt, 0-200°C Input, 0-5 V DC Output

SCM5B34-03D

100 Ω Pt, 0-200°C Input, 0-10 V DC Output

SCM5B34-04

100 Ω Pt, 0-600°C Input, 0-5 V DC Output

SCM5B34-04D

100 Ω Pt, 0-600°C Input, 0-10 V DC Output

SCM5B34-05

100 Ω Pt, -100 - 200°C Input, 0-5 V DC Output

SCM5B34-05D

100 Ω Pt, -100 - 200°C Input, 0-10 V DC Output

SCM5B34C-01

10 Ω Cu (0°C), 0-120°C Input, 0-5 V DC Output

SCM5B34C-01D

10 Ω Cu (0°C), 0-120°C Input, 0-10 V DC Output

SCM5B34C-02

10 Ω Cu (25°C), 0-120°C Input, 0-5 V DC Output

SCM5B34C-02D

10 Ω Cu (25°C), 0-120°C Input, 0-10 V DC Output

SCM5B34C-03

10 Ω Cu (0°C), 0-160°C Input, 0-5 V DC Output

SCM5B34C-03D

10 Ω Cu (0°C), 0-160°C Input, 0-10 V DC Output

SCM5B34N-01D

120 Ω Ni, 0-300°C Input, 0-10 V DC Output
