GS2, 2 kN (0.2 Ton) Assembly Servo Press
The GS2 is a compact servo press offering a maximum force of 2 kN, ideal for lightweight press applications. It provides high precision with repeatability and is suited for a variety of industrial press fitting operations.
Manufacturer : Coretec
Key Features
- Maximum Force Range 2 kN (0.2 Ton)
- Stroke range available – 100 mm
- Maximum actuator speed of 300 mm/sec
- Positional repeatability of ±0.01 mm
- Load cell accuracy of ±1.5% FS (Repeatability ±0.5% FS)
- Brake holding load capacity of 0.5 kN
Specifications
| Max Force | 2 kN (0.1 Ton 450 lbs Force ) |
| Max Speed | 300 mm/s |
| Stroke | 100 mm |
| Interface | Digital I/O Profibus DeviceNet EthernetIP CC-Link |
Downloads
| Servo Press | Brochure |
