WGS3

Velocity and Position Sensor

ASM Sensors, Gmbh

  • Cable Actuated
  • Velocity Sensor with Integrated Position Sensor
  • Potentiometric, Analog or ADSI Output
  • Rectangular Profile Housing
  • Anticorrosive Sheet Steel
  • Connection: Male 8-pin DIN 45326
  • Stainless Steel Cable

Specifications

Type
Draw Wire
Full Scale
3750 mm
5000 mm
7500 mm
Output
0 - 10 V DC
Potentiometric
4 - 20 mA
SSI
Non-Linearity
±0.05 % FS
Resolution
Infinitesimal
Excitation
11 - 27 V DC
12 - 27 V DC
18 - 27 V DC
32 V DC
IP Rating
IP50
Min Temperature
-20 °C
Max Temperature
85 °C

Models

WGS3

Downloads

WGS3 Velocity and Position Sensor
Datasheet
