SCM5B39

Analog Output Modular Signal Convertor

Dataforth

  • Analog Output Module
  • 1500 V Transformer Isolation
  • Accuracy: ± 0.03%
  • Module
  • ANSI/IEEE C37.90.1 Transient Protection
  • Input Protected to 240 V AC Continuous

Specifications

Family
Dataforth 5B
Input Type
0 - 5 V DC
±5 V DC
±10 V DC
0 - 20 mA
# of Inputs
1
Output Type
0 - 20 mA
4 - 20 mA
±20 mA
Bandwidth
275 Hz
400 Hz
Isolation
Yes
Supply Power
5 V DC

Models

SCM5B39-01
0-5 V Input, 4-20 mA Output
SCM5B39-02
± 5 V Input, 4-20 mA Output
SCM5B39-03
0-5 V Input, 0-20 mA Output
SCM5B39-04
± 5 V Input, 0-20 mA Output
SCM5B39-05
0-20 mA Input, 0-20 mA Output
SCM5B39-07
± 10 V Input, ± 20 mA Output
