SCM5B37

Thermocouple Input Analog Modular Signal Conditioner

Dataforth

  • Non-Linearized Thermocouple Input Module
  • 1500 V Transformer Isolation
  • Accuracy: ± 0.03%
  • Module
  • ANSI/IEEE C37.90.1 Transient Protection
  • Input Protected to 240 V AC Continuous

Specifications

Family
Dataforth 5B
Input Type
Thermocouple
# of Inputs
1
Output Type
0 - 5 V DC
0 - 10 V DC
Bandwidth
4 Hz
Isolation
Yes
Supply Power
5 V DC

Models

SCM5B37B
B-Type Thermocouple
SCM5B37C
C-Type Thermocouple
SCM5B37E
E-Type Thermocouple
SCM5B37J
J-Type Thermocouple
SCM5B37K
K-Type Thermocouple
SCM5B37N
N-Type Thermocouple
SCM5B37R
R-Type Thermocouple
SCM5B37S
S-Type Thermocouple
SCM5B37T
T-Type Thermocouple
