SCM5B31

Voltage Input Analog Modular Signal Conditioner

Dataforth

Narrow Bandwidth Voltage Input Module
1500 V Transformer Isolation
Accuracy: ± 0.03%
Module
ANSI/IEEE C37.90.1 Transient Protection
Input Protected to 240 V AC Continuous

Specifications

Family

Dataforth 5B

Input Type

±1 V DC
±5 V DC
±10 V DC
±20 V DC
±40 V DC

# of Inputs

1

Output Type

0 - 5 V DC
0 - 10 V DC
±5 V DC
±10 V DC

Bandwidth

4 Hz

Isolation

Yes

Supply Power

5 V DC

Models

SCM5B31-01

± 1 V Input, ± 5 V DC Output

SCM5B31-01D

± 1 V Input, ± 10 V DC Output

SCM5B31-02

± 5 V Input, ± 5 V DC Output

SCM5B31-02D

± 5 V Input, ± 10 V DC Output

SCM5B31-03

± 10 V Input, ± 5 V DC Output

SCM5B31-03D

± 10 V Input, ± 10 V DC Output

SCM5B31-04

± 1 V Input, 0-5 V DC Output

SCM5B31-04D

± 1 V Input, 0-10 V DC Output

SCM5B31-05

± 5 V Input, 0-5 V DC Output

SCM5B31-05D

± 5 V Input, 0-10 V DC Output

SCM5B31-06

± 10 V Input, 0-5 V DC Output

SCM5B31-06D

± 10 V Input, 0-10 V DC Output

SCM5B31-07

± 20 V Input, ± 5 V DC Output

SCM5B31-07D

± 20 V Input, ± 10 V DC Output

SCM5B31-08

± 20 V Input, 0-5 V DC Output

SCM5B31-08D

± 20 V Input, 0-10 V DC Output

SCM5B31-09

± 40 V Input, ± 5 V DC Output

SCM5B31-09D

± 40 V Input, ± 10 V DC Output

SCM5B31-10

± 40 V Input, 0-5 V DC Output

SCM5B31-10D

± 40 V Input, 0-10 V DC Output
