MAQ20-MV

Millivolt Input Module

Dataforth

  • 8 Millivolt Input Channels
  • Differential Inputs
  • Configurable Channels
  • Input-to-Bus Isolation, 1500 Vrms
  • Channel Overload Protection, 240 Vrms
  • Selective Enabling of Channels for Scanning

Specifications

Family
Dataforth MAQ20
Unit Type
Module
Input Type
Voltage
Analog Inputs
8
Min Temperature
-40 °C
Max Temperature
85 °C

Models

MAQ20-MVDN
8 Millivolt Inputs, Differential
