Beanair® provides a time-synchronization (with an accuracy of 5ms) over the Wireless Sensor Network. The user can launch data acquisition on-demand.
The BeanScape® application allows the user to view all the data transmitted by the BeanDevice® AX-3D XRange. Thanks to the OTAC (Over-the-Air configuration) feature, the user can remotely configure the BeanDevice® AX-3D XRange.
SEVERAL DATA ACQUISITION MODES ARE AVAILABLE ON THE BEANDEVICE® AX-3D XRANGE :
Low Duty Cycle Data Acquisition mode (LDCDA) : the data acquisition is immediately transmitted by radio. The transmission frequency can be configured from 1s to 24h.
Streaming Packet Mode : all measured values are transmitted by packet within a continuous flow at 4000 samples per second maximum
Streaming Mode : all measured values are transmitted in real-time within a continuous flow at 100 samples per second maximum
A Bean scape Premium add on is also available, the BeanScape ® Premium+ integrates an OPC DA server (Data Access). OPC DA is particularly well suited for real time measurement and data sharing. Each data/measurement can be associated to a tag or its attributes and shared with one or many OPC clients.
While the vast majority of wireless sensors show their limits in harsh industrial environment, the BeanDevice® AX-3D XRange integrates an innovative antenna diversity design, boosting the radio link quality in environments subject to random and diverse disturbances. Antenna Diversity improves both the quality and reliability of a wireless link by 30%.
The BeanDevice® AX-3D XRange integrates an embedded Datalogger, which can be used to log data when a Wireless Sensor network can not be easily deployed on your site. All the data acquisition are stored on the embedded flash and then transmitted to the BeanGateway® when a Wireless Sensor Network is established.
The data logger function is compatible with all the data acquisition modes available on your BeanDevice® AX-3D XRange
BeanScape 2.4GHz - How to use the Alarm - Data Acquisition Mode: https://youtu.be/XxWJT7A9ntY
BeanScape 2.4GHz - How to use Low Duty Cycle Data Acquisition Mode: https://youtu.be/TGDBPrFeO_8
Beanscape 2.4GHz - How to perform streaming in Data Acquisition Mode: https://youtu.be/OVVpj0V8svU
How to switch between Standard and Expert HMI View : https://youtu.be/HFtu7HapIeI
