3025

High Output VRS Sensor

  • VRS Sensor
  • Stainless Steel
  • Mounting Thread: 3/8-24 UNF-2A
  • Connection: 24 AWG Vinyl- or PVC-Insulated Leads
  • Simple Installation
  • Self-Powered Operation
  • No Moving Parts

Specifications

Type
Magnetic Pickup
Max Frequency
40 kHz
Mounting
3/8-24 UNF-2A
Connection
24 AWG PVC-Insulated Leads
24 AWG Vinyl-Insulated Leads
Min Temperature
-40 °C
Max Temperature
107 °C

Models

3025A
3/8-24 UNF-2A Thread, 20mm Thread Length, Vinyl-Insulated Leads
3025A17
3/8-24 UNF-2A Thread, 44mm Thread Length, Vinyl-Insulated Leads
3025A35
3/8-24 UNF-2A Thread, 88mm Thread Length, Vinyl-Insulated Leads
3025S13
3/8-24 UNF-2A Thread, 30mm Thread Length, Vinyl-Insulated Leads
3025S23
3/8-24 UNF-2A Thread, 63mm Thread Length, PVC-Insulated Leads
3025SS13
3/8-24 UNF-2A Thread, 30mm Thread Length, PVC-Insulated Leads

Downloads

3025 High Output VRS Sensor
Datasheet
