Key Features

• Weight 28g
• Accuracy ±5% + 2 cc/min
• Max working pressure 10 bar (over 10 bar under request)
• Flow values starting from 200 cc/min
• Made of stainless steel
• SIT certificated calibration
• Stäubli© male connector
• Usable for pressure and vacuum applications
• Pressure full scale: from -1 to 10 bar (customized for the client)
• Flow full scale: (cc/min) : 200
• Different pneumatics available for tubes (mm): Staubli Male, 1/8 Gas Male, 1/4 Gas Male
• Test Gas: Hydrogen, Compressed air, Nitrogen
